Key Specifications/Special Features:
Input Range：100-240VAC
Frequency：50-60 Hz
Input Current：≤0.6A
Inrush Current：≤60A
Efficiency ：Meet CEC Level VI (DoE),     CoC Tier 2
Hold Up Time： ≥8.3mS
Turn On Time：≤3S

Environmental
Operating Temperature：0-40℃
Storage Temperature：-20-85℃
Operating Humidity：10%-90%
Storage Humidity：5%-95%

Safety
EN623668, ETL, FCC, PSE, GS, CE, CCC
Electrical Specifications
Max. Output Power (W)：5-6W
Output Voltage (vo)： 5V
Min. Load (io) ：0.1-1.2A
Ripple & Noise：100mV

Features
DoE Compliance
RoHS Compliance
Over Voltage Protective Installation
Short Voltage Protective Installation
Protection Type: Auto Recovery
MTBF: 100,000 hrs

Shipping Information
FOB Port Shenzhen
Lead Time 25–30 days
US HTS Code 8504.40.60 01

Main Export Markets
- Asia
- Eastern Europe
- North America
